功能點Feature and functions
●三層不銹鋼結構，內膽、外筒、面板均采用耐酸堿、抗腐蝕的強度304不銹鋼制造；內膽采用2.5mm厚度的304質不銹鋼材料焊接而成，機身四面外殼采用304不銹鋼裝飾板制作。
●口徑不銹鋼裝載門，配備安門鎖，美觀耐用、安可靠。
●主軸軸承采用日本NSK、NTN或意利CCVI等其名產品。
●采用變頻調速控制，節省電力，降噪音，運轉加平穩可靠。
●壓電器采用的名電氣元器件，使用可靠，穩定性好。
●采用性能可靠的中文液晶電腦自動控制器，美觀方，操作簡單。
●Three layers stainless steel structure inner outer tube panel adopts acid and alkali resistance corrosion of high strength 304 stainless steel manufacturing; A 2.5 mm thickness of the tank 304 high quality stainless steel welded together the fuselage shell adopts 304 stainless steel decorative materials production in all directions.
●Large stainless steel loading door equipped with safe door latch beautiful and durable safe and reliable.
●The bearing of key parts are all world famous products such as Japanese NSK、NTN or Italian CCVI.
●Frequency control electricity saving and noise decreasing reliable and stable.
●The low-voltage apparatus are all top grade electric components with high quality reliable and stable.
●Full automatic control by computer board in Chinese reliable and beautiful easy to operate.
●三層不銹鋼結構，內膽、外筒、面板均采用耐酸堿、抗腐蝕的強度304不銹鋼制造；內膽采用2.5mm厚度的304質不銹鋼材料焊接而成，機身四面外殼采用304不銹鋼裝飾板制作。
●口徑不銹鋼裝載門，配備安門鎖，美觀耐用、安可靠。
●主軸軸承采用日本NSK、NTN或意利CCVI等其名產品。
●采用變頻調速控制，節省電力，降噪音，運轉加平穩可靠。
●壓電器采用的名電氣元器件，使用可靠，穩定性好。
●采用性能可靠的中文液晶電腦自動控制器，美觀方，操作簡單。
●Three la
●Large stainless steel loading door equipped with safe door latch beautiful and durable safe and reliable.
●The bearing of key parts are all world famous products such as Japanese NSK、NTN or Italian CCVI.
●Frequency control electricity saving and noise decreasing reliable and stable.
●The low-voltage apparatus are all top grade electric components with high quality reliable and stable.
●Full automatic control by computer board in Chinese reliable and beautiful easy to operate.
技術參數Technical parameters
|
型號 model 項目 item |
單位/unit | QXSQ-1000 | QXSQ-1200 | QXSQ-1500 | QXSQ-2000 | QXSQ-2500 | |
| 容量 | Capacity | kg | 10 | 12 | 15 | 20 | 25 |
| 滾筒直徑 | Drum Diameter | mm | 580 | 580 | 660 | 760 | 800 |
| 滾筒深度 | Drum Diameter | mm | 380 | 460 | 436 | 460 | 500 |
| 洗滌轉速 | Washing speed | r/min | 40 | 40 | 40 | 40 | 40 |
| 洗滌驅動電機功率 | Motor | KW | 1.1 | 1.1 | 1.1 | 2.2 | 3 |
| 洗滌加熱器功率 | Heating | KW | 6 | 6 | 6 | 9 | 12 |
| 裝機容量（蒸汽） | Inst. Power(Steam | kg | 1.1 | 1.1 | 1.1 | 3 | 3 |
| 進水徑 | Water Inlet | inch | 1” | 1” | 1” | 1” | 1” |
| 排水徑 | Water outlet | inch | 2” | 2” | 2” | 2” | 2” |
| 寬 | Width | mm | 820 | 890 | 960 | 1050 | 1140 |
| 深 | Depth | mm | 880 | 880 | 880 | 1070 | 1220 |
| Height | mm | 1100 | 1100 | 1150 | 1360 | 1460 | |
| 機器凈重 | Net Weight | kg | 460 | 480 | 520 | 580 |
680 |
